Experience of low-rise residential houses design and construction built from factory-made reinforced concrete panel items is considered. It is noted that in this type of housing construction house-building plant and large-panel housing construction plants products is widely used. However, in most cases, products for multi-storey construction panel buildings are used directly for low-rise cottages. This approach is ineffective for many reasons, but mainly due to size and weight of the used products. The variant design made it possible to set optimized parameters for the length, height and weight of the exterior and interior walls load-bearing panels. Use of the double-layer exterior wall panels is the main technique that reduces buildings weight and allows variability of low-rise buildings facade finishes. The third layer exclusion makes it possible to reduce the exterior panels weight by 20–30%, increase the products length to 8.5 m, and reduce number of mounting elements in one- and two-story buildings by 25–50%, depending on the number of floors and buildings under construction spatial planning solutions. The above optimized product parameters for the low-rise panel buildings were tested during construction of 6 two-storey buildings with the area of 147 and 180 m2 in the Moscow region in 2022–2024. Based on these houses building experience effectiveness of their construction is shown. Usage of double–layer exterior wall panels with optimized parameters of other house kit products allows reducing the cost of one cottage house by 0.8–1 million rubles.

全文:

受限制的访问

作者简介

S. Nikolaev

AO «TSNIIEP zhilishcha» – institute for complex design of residential and public buildings» (AO «TSNIIEP zhilishcha»)

编辑信件的主要联系方式.
Email: slutz1937@gmail.com

Doctor of Sciences (Engineering), Honored Builder of the Russian Federation, Director of Science

俄罗斯联邦, 9/3, Dmitrovskoe Highway, Moscow, 127434

参考

  1. Guryev V.D., Yakhkind S.I. The main trends in the development of civil engineering at the present stage. Academia. Arxitektura i Stroitel’stvo. 2022. No. 3, pp. 97–103. (In Russian). EDN: UEPRMZ. https://doi.org/10.22337/2077-9038-2022-3-97-103
  2. Nikolaev S.V. Housing availability and birth rate. Stroitel’nye Materialy [Construction Materials]. 2025. No. 1–2, pp. 79–83. (In Russian). https://doi.org/10.31659/0585-430X-2025-832-1-2-79-83
  3. Tsypin A.P., Kabanova E.E., Gadzhimirzoev G.I. Statistical analysis of housing availability In Russian regions. Izvestiya of Saratov University. New series. Series: Economics. Management. Law. 2023. Vol. 2/3. Iss. 1, pp. 27–34. (In Russian). EDN: FTFMTV. https://doi.org/10.18500/1994-2540-2023-23-1-27-34
  4. Prokofieva L.M., Korchagina I.I. The demographic structure of families and households In Russia, its dynamics according to population censuses. Demograficheskoe Obozrenie. 2023. Vol. 10. No. 2, pp. 4–17. (In Russian). EDN: TDYEBV. https://doi.org/10.17323/demreview.v10i2.17763
  5. Vasiliev A.N. Industrial housing construction as an element of Russia’s new industrial policy. Economica I Menedgment System Upravleniya. 2022. No. 4 (46), pp. 15–21. (In Russian). EDN: QBRXWC
  6. Nikolaev S.V. Two-layer external panel in industrial buildings. Zhilishchnoe Stroitel’stvo [Housing Constructions]. 2023. No. 10, pp. 9–13. (In Russian). EDN: PVMSEB. https://doi.org/10.31659/0044-4472-2023-10-9-13
  7. Nikolaev S.V. Two-layer factory-made exterior panel for low-rise housing construction. Zhilishchnoe Stroitel’stvo [Housing Construction]. 2023. No. 3, pp. 3–10. (In Russian). EDN: NHDZOD. https://doi.org/10.31659/0044-4472-2023-3-3-10
  8. Nikolaev S.V. Construction of low-rise housing from house sets of factory production. Zhilishchnoe Stroitel’stvo [Housing Construction]. 2021. No. 5, pp. 3–8. (In Russian). EDN: NYBMBG. https://doi.org/10.31659/0044-4472-2021-5-3-8
  9. Shembakov V.A. Tasks and prospects for the development of the Russian construction industry. Stroitel’nye Materialy [Construction Materials]. 2024. No. 3, pp. 4–7. (In Russian). EDN: KKPBJW. https://doi.org/10.31659/0585-430X-2024-822-3-4-7
  10. Sokolov N.S., Sokolov S.N., Sokolov A.N. The practice of construction in particularly cramped conditions. Zhilishchnoe Stroitel’stvo [Housing Construction]. 2023. No. 9, pp. 41–47. (In Russian). EDN: AZVVDS. https://doi.org/10.31659/0044-4472-2023-9-41-4
  11. Kazin A.S. Technological sovereignty in the Russian construction industry. Zhilishchnoe Stroitel’stvo [Housing Construction]. 2024. No. 3, pp. 8–11. (In Russian). EDN: WFVKSV. https://doi.org/10.31659/0044-4472-2024-3-8-11
  12. Guryev V.V., Dmitriev A.N., Yakhkind S.I. Experimental and standard design – a strategic vector of development of industrial civil construction. Promyshlennoe i Gragdanskoe Stroitelstvo. 2022. No. 7, pp. 40–47. (In Russian). EDN: NAIPTA. https://doi.org/10.33622/0869-7019.2022.07.40-47

补充文件

附件文件
动作
1. JATS XML
下载
2. Fig. 1. The outer panel support unit on the grillage: a – the living room and kitchen plan; b – the panel support unit on the grillage; c – the 3.6 m span double-layer exterior panel with reinforced lower belt; d – view from the living room; e – view from the outside

下载 (408KB)
索引源数据
3. Fig. 2. Plans and facades of 120 m2 cottages: 1 – one-storey; 2 – two-storey

下载 (479KB)
索引源数据
4. Fig. 3. The double-layer exterior wall panels: a – cross section; b – layers: bearing 140 mm, insulation with embedded parts 100–150 mm, facade with a plaster layer of 20 mm, 20 mm facade plank (Planken) or 70 mm thermal panels; c – the facade finishing options; d – the exterior panels appearance before façade finishing; e – finishing with thermal panels on overhead details; f – plaster and plank (Planken) finishing

下载 (359KB)
索引源数据
5. Fig. 4. Installation of a 7420 mm length and 6025 kg weight panel

下载 (198KB)
索引源数据
6. Fig. 5. Panel houses construction in the Moscow region (KP "Favorit", Kiev highway)
